Small Size Portable COFDM Receiver Wireless AV Receiver 300MHz-800MHz

Product Features:

1. Small size and lightweight;
2. Easy to be carried,good quality;
3. Safe and reliable;
4. Stereo audio output;
5. <-105dBm Sensitivity:
6. COFDM modulation,MPEG-2 coding

Specifications:

1. Frequency: 300-800MHz(optional),1.2GHz/2.4GHz/5.8GHz(customized);
2. Sensitivity: <-105dBm
3. RF Interface: N(F)
4. Power supply: DC12V/AC220V
5. Modulation: COFDM, 2K
6. AV Interface: BNC
7. FEC: 1 / 2
8. Guard Interval: 1 / 32
9. Video Output: 1 line PAL / NTSC analog video
10. Revolution: 720*576
11. Lines of horizontal: 625 or 525 Line
12. Audio Output: Analog stereo left and right channels
13. Work environment: -30~70
14. Weight: 900g
15. Size: 140*170*30mm

Kimpok Technology is a leading of High-tech global enterprise in developing and manufacturing. Company established in 1998 and located in Shenzhen China. Specializing in the provision of advance wireless microwave communication system to the broadcast, UAV, public surverillance and defense industries. By continuously investing in innovation and combining exceptional products and services, Kimpok offers superior solutions that enable our customers to do their jobs even more effectively.

Kimpok Technology has a very strong technical team and R&D capacity. we dedicated to developing the high level wireless mobile video surveillance system for application of Law enforcement and military, field forces, radar, R/C helicopter, security & protection, government departments, military, security systems, oil field, Vessel, large mines, factories and so on.

Last for 15 years, Kimpok Technology continually concentrate on researching and innovating in the wireless high speed mobile video transmission industry based in LOS/NLOS environments,especial for Unmanned aircraft vehicle(UAV), airborne area and soldier man-pack areas. COFDM modulation and TDDworking mode transmitter/receiver are our demonstrable advantages.All the products production must be in very strict quality management by using US original (HP) spectrum analyzer and Germany (Rohde & Schwarz) Network Analyzer.

The transmitter and receiver are with Anti-jamming, high quality image, long range transmission distance, and have a highly appraise in this area. Company’s developing and long-term programming is the key way for leading us to be the leader at this area, we always believe we can do it. We will continually concentrate on researching and innovating in the wireless microwave transmission industry.

Welcome to tell use your needs, we will try to meet your requirements and custom made a special device for you.” Your support and suggestions are our motivation”. We aim to provide our users worldwide exclusive advanced wireless videography system.
