Full HD COFDM IP Transmitter Wireless Microwave Data Link RJ45 And RS232

Main Feature:

1) Provide up to 6.5Mbps of data flow, dynamic adaptive rate allocation technology;

2) Smart settings, simple operation, easy to use;
3) Support transparent PTMP network technology;
4) Safety with AES 128 bit, can set user’s password;
5) Support non line of sight ( NLOS ) high-speed mobile transmission;
6) Provide standard RS-232&RS-485 + RJ45 ethernet;
7) Transmit/receive video audio, data and other multimedia signals simultaneously;
8) Support high standards of Industrial and military level applications;
9) The small volume, light weight, easy to carry, the radiating aluminum casing;
10) High clear OLED digital display, the interface simple and easy operation.

Product Parameters:

Power supply	DC7V～17V, 6W consumption
Ethernet	10/100BaseT,Auto-MDI/X,IEEE802.3
	TCP,UDP,TCP/IP,TFTP,ARP,ICMP,DHCP,HTTP,SNMP,FTP,DNS
Output frequency	2405～2470MHz(adjustable)
Output rf power	100-1000mW(30dBm) (adjustable)
Bandwidth	4MHz/8MHz (adjustable)
Interface	RJ-45 ethernet ,RS232/RS485/RS422
Reolution	Support 720P and 1080P@50/60hz, 30 frames
Encryption mode	128bit AES(or 256bit AES)
Error correction mechanism	32bit of CRC,ARQ
Modulation	TDD_COFDM
Parameter control	Through OLED control panel to modify parameters
Working temperature	-40℃～85℃
Dimension	75*51*22mm
Weight	135g

Product Application:

It has advantange of small volume and light weight,especially widely used in UAV/ drones /Quadcopter/Octocopter/hexacopter, WIFIBOT Network building and etc.. such fast-moving complex environment video data signals transmission.

Test equipments:

Kimpok Technology is a leading of High-tech global enterprise in developing and manufacturing. Company established in 1998 and located in Shenzhen China. Specializing in the provision of advance wireless microwave communication system to the broadcast, UAV, public surverillance and defense industries. By continuously investing in innovation and combining exceptional products and services, Kimpok offers superior solutions that enable our customers to do their jobs even more effectively.

Kimpok Technology has a very strong technical team and R&D capacity. we dedicated to developing the high level wireless mobile video surveillance system for application of Law enforcement and military, field forces, radar, R/C helicopter, security & protection, government departments, military, security systems, oil field, Vessel, large mines, factories and so on.

Last for 15 years, Kimpok Technology continually concentrate on researching and innovating in the wireless high speed mobile video transmission industry based in LOS/NLOS environments,especial for Unmanned aircraft vehicle(UAV), airborne area and soldier man-pack areas. COFDM modulation and TDDworking mode transmitter/receiver are our demonstrable advantages.All the products production must be in very strict quality management by using US original (HP) spectrum analyzer and Germany (Rohde & Schwarz) Network Analyzer.

The transmitter and receiver are with Anti-jamming, high quality image, long range transmission distance, and have a highly appraise in this area. Company’s developing and long-term programming is the key way for leading us to be the leader at this area, we always believe we can do it. We will continually concentrate on researching and innovating in the wireless microwave transmission industry.

Welcome to tell use your needs, we will try to meet your requirements and custom made a special device for you.” Your support and suggestions are our motivation”. We aim to provide our users worldwide exclusive advanced wireless videography system.
